Medium Combustion Plant Directive (MCPD): Monitoring of Emissions and Assessment of Compliance
Foundry | Post-combustion plants | Co-fired and multi-fuelled MCPs | District heating plants | Biomass | Power generation | Cement | …
The Medium Combustion Plant Directive (MCPD) applies to over 140,000 plants in the EU, and regulates emissions from the combustion of fuels in plants with a rated thermal input between 1 and 50 MW. Part of the Clean Air Policy Package the MCPD also implements obligations arising from the Gothenburg Protocol under the UNECE Convention on Long-Range Transboundary Air Pollution. This Directive fills the regulatory gap at EU level between large combustion plants (> 50 MWth), covered by the Industrial Emissions Directive (IED) and smaller appliances (heaters and boilers <1 MWth) covered by the Ecodesign Directive.
The MCPD addresses the potential need for Member States to apply stricter emission limit values in areas where this can improve local air quality in a cost-effective way.

The MCPD regulates emissions of SO2, NOX and dust to air, and compliance will also require the monitoring of CO emissions. Each permit’s emission limit values (ELVs) are dependent on plant, fuel type and size.
The ELVs established by the MCPD apply from 20 December 2018 for new plants and 2025 or 2030 for existing plants, depending on their size. The MCPD addresses the potential need for Member States to apply stricter emission limit values in areas where this can improve local air quality in a cost-effective way.

Responding to the requirements of the MCPD, ENVEA has developed a new generation of eco-designed, ultra-compact and cost effective NDIR (non-dispersive infrared) CEMS, offering high precision and a fast response time. The monitor requires only limited maintenance, and allows simultaneous measurement of NOx, SO2, CO, O2, residual H2O, and optionally Greenhouse Gases. Particulates can be monitored independently, with the use of advanced electrodynamic device. Insensitive to T° variations in the range +5° to +40°C (no air conditioning required), this new generation of CEMS is compatible with any type of drying technology (gas cooler, permeation, dilution etc.). Other key features include compliance of the AMS with EN14181 & EN15267-3 (QAL1), remote communication, and AMS control functionalities such as integrated sampling control, automatic zero and span gas injection, external pump control, and system alarms display.

Recommended monitoring solutions:

Watch the video to learn more:
